Rear wheel

SWINGING ARM FOR VESPA SPRINT 4T 3V IE 2015

Brakes pipes - Calipers

Item numbers
Swinging arm VESPA VESPA-SCOOTER 150 SPRINT 2015 Sprint 4T 3V ie
1
2
2
3
3
3
4
5
5
6
6
7
8
9
10
11
12
13
13
14
15
16
16
17
18
19
19
20
21
1
COMPLETE SWINGING ARM ON FRAME SIDE

5A000483  

Unit Price Incl. Tax

2
BUSH

598917  

Unit Price Incl. Tax

3
ROLLER CAGE

600161  

Unit Price Incl. Tax

4
COMPLETE SWINGING ARM ON ENGINE SIDE

5A000485  

Unit Price Incl. Tax

5
BUSH

597317  

Unit Price Incl. Tax

6
ROLLER CAGE

56127R  

Unit Price Incl. Tax

7
SPACER

1C000439  

Unit Price Incl. Tax

8
HEX SOCKET SCREW M12X324

597914  

Unit Price Incl. Tax

9
WASHER

266845  

Unit Price Incl. Tax

10
SPACER

1C000449  

Unit Price Incl. Tax

11
NUT M12

271740  

Unit Price Incl. Tax

12
SPACER

1C000440  

Unit Price Incl. Tax

13
HEX SCREW M10X202

271807  

Unit Price Incl. Tax

14
SELF LOCKING NUT M10

002440  

15
COMPLETE SILENT BLOCK SUPPORT BRACKET
ASSEMBLED SILENTBLOC BRACKET

1C000502  

1C0005025

Unit Price Incl. Tax

16
SILENT BLOCK
BUFFER

668514  

1C002624

Unit Price Incl. Tax

17
CIRCLIP

006416  

Contact
18
SILENT BLOCK COVER

1C000421  

Unit Price Incl. Tax

19
HEX SCREW

1C000608  

Unit Price Incl. Tax

20
FLAT WASHER

178790  

Unit Price Incl. Tax

21
SELF LOCKING NUT M10

002440  

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Swinging arm of your VESPA Sprint 4T 3V ie of SPRINT. Let us know if you have any questions.

Genuine parts for VESPA Sprint 4T 3V ie 2015
