FORK / STEERING TUBE - STEERING BEARING UNIT FOR VESPA SPRINT 4T 3V IE 2015

Front wheel

Item numbers
Fork/steering tube - Steering bearing unit VESPA VESPA-SCOOTER 150 SPRINT 2015 Sprint 4T 3V ie
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29
30
30
31
32
33
33
33
33
34
35
36
37
38
39
40
41
41
42
43
44
45
46
47
48
49
50
51
52
53
54
1
STEERING TUBE COMPLETE WITH ARM

6736595  

Unit Price Incl. Tax

2
LEFT SUSPENSION ARM

6691315  

Unit Price Incl. Tax

3
ROLLER CAGE

198513  

Unit Price Incl. Tax

4
GASKET RING

119219  

Unit Price Incl. Tax

5
GASKET

006731  

Contact
6
PISTON PIN

177451  

Unit Price Incl. Tax

7
STEERING TUBE RING NUT

0111094  

Contact
8
WASHER OF THE STEERING

0037514  

Contact
9
UPPER THRUST RING

65069345  

Unit Price Incl. Tax

10
RONDELLE DE BUTÉE INFÉRIEURE
BEARING

650075  

65007545

Unit Price Incl. Tax

11
COMPLETE FRONT SUSPENSION COVER

673645  

1C001165

Unit Price Incl. Tax

12
METRIC SCREW M6X22

CM179201  

Unit Price Incl. Tax

13
NUT

969224  

Unit Price Incl. Tax

14
FRONT SHOCK ABSORBER CPL.

1C000843R  

Unit Price Incl. Tax

15
PAD

174874  

Unit Price Incl. Tax

16
CONSOLE DE FIXATION AMORTISSEUR
BRACKET WITH I.P.

668767  

1C004308

Unit Price Incl. Tax

17
BRIDE DE SUPPORT DU TUYAU DE FREIN
BRAKE HOSE BRACKET

1C000327  

1C003390

Unit Price Incl. Tax

18
PAD

174085  

Unit Price Incl. Tax

19
WASHER

174088  

Unit Price Incl. Tax

20
WASHER

012535  

Contact
21
NUT

021210  

Contact
22
SCREW

597150  

Unit Price Incl. Tax

23
SPRING WASHER 13, 75X8, 15X4, 5

016408  

Unit Price Incl. Tax

24
CAPUCHON DE PROTECTION DES RONDELLES DE BUTÉE
PROTECTION CUP

665735  

1B004779

Unit Price Incl. Tax

25
WASHER

177445  

Unit Price Incl. Tax

26
O-RING

177408  

Unit Price Incl. Tax

27
RING

177521  

Unit Price Incl. Tax

28
PIN AND SHOCK ABSORBER SUPPORT

6691285  

Unit Price Incl. Tax

29
DRAWN CAP

177436  

Unit Price Incl. Tax

30
ROLLER CAGE

1C000167  

Unit Price Incl. Tax

31
RING

177494  

Unit Price Incl. Tax

32
THREADED PIN

1C000500  

Unit Price Incl. Tax

33
CIRCLIP

006422  

Contact
34
THREADED BUSH

1C000499  

Unit Price Incl. Tax

35
WASHER

847183  

Unit Price Incl. Tax

36
WASHER

177414  

Unit Price Incl. Tax

37
GASKET RING

482302  

Unit Price Incl. Tax

38
SAFETY WASHER

006408  

Contact
39
GASKET RING

177443  

Unit Price Incl. Tax

40
ROLLER CAGE

177442  

Unit Price Incl. Tax

41
BRAKE DISC

56395R  

Unit Price Incl. Tax

41
BRAKE DISC

5A000183  

Unit Price Incl. Tax

42
HEX SCREW

1C000291  

Unit Price Incl. Tax

43
FRONT WHEEL HUB WITH I.P.

1C000383  

1C0003836

Unit Price Incl. Tax

44
BEARING

177610  

Unit Price Incl. Tax

45
SNAP RING

006635  

Contact
46
NUT

021114  

Contact
47
CAP

177609  

Unit Price Incl. Tax

48
SPLIT PIN

012789  

Contact
49
COVER

5A000238  

Unit Price Incl. Tax

50
COVER

601026  

Unit Price Incl. Tax

51
SPEED SENSOR FOR ODOMETER

5A0001685  

Contact
52
HEX SOCKET SCREW M6X16

709099  

Unit Price Incl. Tax

53
FLAT WASHER

668780  

Unit Price Incl. Tax

54
SWIVEL ARM COVER

1C0008405  

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Fork/steering tube - Steering bearing unit of your VESPA Sprint 4T 3V ie of SPRINT. Let us know if you have any questions.
