CRANKCASE FOR VESPA SPRINT 4T 3V IE 2015

Rear brake - Brake jaw

Item numbers

COMPLETE CRANKCASE 1ST CAT.
COMPL. CRANKCASE 1ST CLASS PARE PART

CM1682010001

CM2658010A

£905,16

Unit Price Incl. Tax

2ND CAT. COMPLETE CRANKCASE
COMPL. CRANKCASE 2ND CLASS SPARE PART

CM1682010002

CM2658010B

£905,16

Unit Price Incl. Tax

COMPLETE CRANKCASE 1ST CAT.

CM2658010A

£905,16

Unit Price Incl. Tax

2ND CAT. COMPLETE CRANKCASE

CM2658010B

£905,16

Unit Price Incl. Tax

NOZZLE

B018059

£7,08

Unit Price Incl. Tax

PIN D.9, 5 H=15

B015956

£0,71

Unit Price Incl. Tax

PLUG M12X1, 5X11

B015433

£7,50

Unit Price Incl. Tax

CALIBRATED NOZZLE

880706

£8,88

Unit Price Incl. Tax

LOCATING DOWEL

B015957

£0,95

Unit Price Incl. Tax

RADIAL BEARING 20X50X14

83027R

£10,66

Unit Price Incl. Tax

RADIAL BEARING 15X42X13

83026R

£5,26

Unit Price Incl. Tax

STUD BOLT
STUD

879887

1A001406

£4,07

Unit Price Incl. Tax

SILENT-BLOCK
SILENTBLOC

B015437

486081

£9,31

Unit Price Incl. Tax

GASKET

431065

£0,86

Unit Price Incl. Tax

CIRCLIP 25X26, 9X1, 2

B015959

£1,21

Unit Price Incl. Tax

SEALING RING 22X35X7
SEAL RING 22.35.7

B014137

1A005834

£5,69

Unit Price Incl. Tax

RING CONTAINER LAMINATION

876646

£4,77

Unit Price Incl. Tax

SCREW M5X10
SCREW FOR OUTER H.T. COIL (M5X10)

B016000

018575

£2,77

Unit Price Incl. Tax

OIL PRESSURE ADJUSTING VALVE

B015432

Contact

SCREW W/ FLANGE M6X60
HEXAGONAL RANGE HEAD SCREW

1A000322

B016425

£1,55

Unit Price Incl. Tax

GASKET
CRANKCASE GASKET

B015429

875111

£15,34

Unit Price Incl. Tax

SCREW W/ FLANGE M5X16

830061

£2,37

Unit Price Incl. Tax

OIL BULHEAD

B014134

£9,22

Unit Price Incl. Tax

UPPER OIL BULKHEAD

B014135

£6,80

Unit Price Incl. Tax

VALVE SPRING

B015431

£1,17

Unit Price Incl. Tax

FILTER DOOR INSERT

B015430

£6,03

Unit Price Incl. Tax

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from VESPA. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Crankcase of your VESPA Sprint 4T 3V ie of SPRINT. Let us know if you have any questions.
